335 Thermoelectric temperature sensor Ex d (Ex t, Ex i) to thermowell DIN with connecting screw-joint on adapter without converter

335

Need help?

call +420 493 761 394

Mo - Fr 06:00 - 14:00


  • For exact remote measurement of temperature of steady and running liquids (gases and fluids), for which the properties of the thermowell of the sensor selected by the customer are suitable; measurement may be realized up to temperature (max. 450°C) and pressure determined by thermowell resistance
  • For environment with explosive gaseous atmosphere according to EN 60079-10-1 and explosive atmospheres with combustible dust according to EN 60079-10-2
    - Sensor may be installed into the thermowell located in zone 0, 1, 2, 20, 21 and 22; for zone 0 the thermowell must comply with the requirements pursuant to EN 60079-26 (see Figure 5)
    - Other parts of the sensor (screw-joint, adapter, connecting head) may be located in zone 1(21) or zone 2(22)
    - Sensor without converter or converter with Ex ia version, when connected to Ex ia circuit according to EN 60079-25 in zone 0, 1, 2, 20, 21 and 22
  • In a set with control or diagnostic systems for process monitoring
  • In design with converter for transfer of thermoelectric sensor signal to unified output signal 4 to 20 mA or digital signal (converter with HART protocol)
  • In design with display to display the value of the measured value
  • For the environment, where mechanical resistance is required pursuant to EN 60068-2-6 (class AH2) and seismic capability of the electrical equipment of the safety system of the nuclear power stations pursuant to IEC 980 (MVZ level SL-2 )
  • The sensors are rated products pursuant to the Directive 2014/34/EU, 2014/30/EU of the European Parliament and the Council and EU Declaration of Conformity EU -335000 is issued for them.
